Summary

The XSONIC SS260 from Airmar is a stainless steel, thru-hull broadband transducer, the perfect choice for sportfishing and commercial vessels up to 30ft (9m)in length.

Productinformation

The XSONIC SS260 from Airmar is a stainless steel, thru-hull broadband transducer, the perfect choice for sportfishing and commercial vessels up to 30ft (9m)in length.

  • High Performance:
    The 1kW transducer is perfect for fast, sportfishing vessels that can install a thru-hull transducer with a fairing.
  • Deep Water Fishing:
    Excellent for deep water bottom and structure fishing up to 500m/1640ft.
  • Depth/Temperature:
    Calculate depth and temperature from one compact sensor.
  • Easy To Install and Wide Operating Range:
    From 1 knot to 45 knots.
  • Highly Accurate Sounding:
    Provides extremely accurate echosounding data, even at speeds of over 30 knots.
  • Dual Elements:
    The narrow, 6° beam 200 kHz ceramic offers excellent resolution and and crisp image detail for bottom fishing. The seven-element 50 kHz array has a wider 19° beam for deepr blue-water fishing.
  • Stainless Steel:
    Built to withstand the environment.

- Dimensions: W x H x D114 x 216 x 244 mm (W, L, D) (4.5 X 8.5 X 9.6") without fairing block
- Frequencies: 50/200 kHz
- Weight7.3 kg ( 16 lb)
- Max Depth735m (2400 ft) (low frey) depending on sonar
